• LF (brown in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Stainless steel base chain.

Technical Specifications

Series	TableTop 1843 Series Side-flexing Chain
Product Group	Chain
Flight Thickness (in)	0.13 in
Product Line	Conveying Chains and Belts
Product Type	Side-Flexing
Flight Thickness (mm)	3.2 mm
Curve Retention Type	TAB
Breaking Load (lb)	2,250 lb
Weight (kg/m)	0.7 kg/m
Weight (lb/ft)	0.5 lb/ft
Surface Type	Solid Top
Base Chain Material	Stainless Steel
Chain Pitch (in)	1 in
Chain Material Description	Tan Low Friction
Breaking Load (N)	10,000 N
Chain Material	LF
Straight or Side-Flex	Side-flexing
Chain Width (in)	1.25 in
Chain Width (mm)	31.75 mm
Chain Pitch (mm)	25.4 mm
Chain Number	1843TAB
Chain Width Measurement System	Imperial

General Specifications

UPC	726166148683
Weight	0.61 LB
Packaged Length	10.00 IN
Packaged Width	9.90 IN
Packaged Height	1.70 IN
HTC	7315.11.0060
Country of Origin	Germany
