• Multiflex chain.
• LFW (white in color) acetal material is commonly used in the market and offers an improved coefficient of friction and is suitable for use in high speed applications.
• Austenitic stainless steel pin.

Technical Specifications

Series	TableTop 1701 Series Side-flexing Chain
Flight Thickness (in)	0.98 in
Product Line	Conveying Chains and Belts
Product Group	Chain
Product Type	Side-Flexing
Flight Thickness (mm)	24.9 mm
Weight (lb/ft)	0.9 lb/ft
Chain Number	1701TAB
Curve Retention Type	TAB
Surface Type	Solid Top
Weight (kg/m)	1.4 kg/m
Rod/Pin Material	Austenitic stainless steel
Chain Width (mm)	53.1 mm
Chain Material Description	Tan Low Friction
Chain Pitch (in)	1.97 in
Breaking Load (lb)	2,100 lb
Chain Width (in)	2.09 in
Straight or Side-Flex	Side-flexing
Chain Pitch (mm)	50 mm
Breaking Load (N)	9,500 N
Chain Width Measurement System	Metric
Chain Material	LF

General Specifications

UPC	726166181987
Weight	1.09 LB
Packaged Length	10.30 IN
Packaged Width	11.40 IN
Packaged Height	5.00 IN
HTC	3923.29.0000
Country of Origin	Germany
