Механический выключатель Bosch Rexroth 20 BG [R023620301]

Electrical accessories for linear axes

Mechanical switch

Use

Limit switch

Attachments

with

Connection type

Screw connection, without line

Type of operating voltage

AC

Switching function version

Single-pole changeover/(NC: C+NC, NO: C+NO)

Permissible ambient temperature (min. ... max.)

-5 °C ... +85 °C

B10d value

5x106 (wet area); 10x106 (dependent on current load (dry area))

Weight [kg]

0.13

Function indicator

no

Functional principle

mechanical, roller

Compatible

SGK, SOK

Load current [A]

≤5

Max. permissible approach speed [m/s]

1

Option number

15

Switching frequency

3.3

Protection class

IP67
