• 3 11/16" Mounted Spherical Roller Bearing, Cast Iron Fixed 2-Bolt Pillow Block, Single Setscrew Locking Collar, Spring Loaded Heavy Contact Seal

Dimensions

Slot Length (in)	1.75 in
Overall Height (in)	8.5 in
Base to Center Height (in)	4.125 in
Bolt Size (in)	1 in
Overall Length (in)	14.25 in
Bore Diameter (in)	3.6875 in
Foot Height (in)	2.13 in
Base Width (in)	4.13 in
Overall Width (in)	5.13 in
Locking Collar Outside Diameter (in)	5.63 in
Base Length (in)	14.25 in
Housing Cast Face to Outermost Bearing Face (in)	1.03 in
Inner Ring Outside Diameter (in)	4.561 in
Length Through Bore (in)	5.13 in
Bolt Spacing (in)	10.88 in

Technical Specifications

Housing Material	Cast Iron
Static Load Rating (lb)	137,000 lb
Housing Color	Black
Shaft Locking Type	Single Set Collar
End Cap	DTC11
Rolling Element	Spherical Roller
Seal Type	Heavy Contact Seal
Product	ZA2000
Misalignment Type	Dynamic
Fixed/Expansion	Fixed
Housing Style	Pillow Block
Radial Clearance	C3 STANDARD
Cage Material	Engineered Polymer
Housing Construction	Solid
Housing Type	Pillow Block, Two Bolt
Series	Solid-housed Pillow Blocks
Radial Dynamic Load Capacity (lb)	130,970 lb
Setscrew Torque (in-lbs)	1350 in/lbs
Available Seal Type	K Light Contact Lip Seal; M Spring Loaded Heavy Contact Lip Seal (Buna and Viton); Z Clearance Seal; G Triple Lip
Ability to Relubricate	Yes
Maximum Speed (RPM)	1200 rpm
Microlock Kit	ML4
Seal Kit	MS11
Primary Seal	BUNA SPRING LOADED LIP SEAL
Vibration Frequency Inner Ring Defect	0.1717 cps
Locking Device Kit	SC11
Misalignment Capability	±2.0° Misalignment - Dynamic
Grease Fitting Thread Size	1/8 NPT
Size Code	11
Max Operating Temperature (C)	107 °C
Vibration Frequency Fundamental Train	0.0071 cps
Insert	2311U
Max Operating Temperature (F)	225 °F
Vibration Frequency Roller Spin	0.0548 cps
Vibration Frequency Outer Ring Defect	0.1283 cps
Lubricant	EXXON RONEX MP STD
Housing Coating	POWDER COATED

General Specifications

UPC	698210632700
Weight	58.00 LB
Packaged Length	15.50 IN
Packaged Width	5.38 IN
Packaged Height	8.50 IN
Country of Origin	Mexico
