• 2 3/16" shaft size; Cast iron housing; Fixed unit; Setscrew mounting collar; Triple lip seal; Exxon Ronex MP grease; Accessories include open cap and closed cap

Dimensions

Overall Length (in)	9.61 in
Bolt Size (in)	5/8 in
Base Width (in)	2.56 in
Overall Height (in)	4.99 in
Slot Length (in)	0.88 in
Foot Height (in)	1.5 in
Bore Diameter (in)	2.1875 in
Base to Center Height (in)	2.5 in
Overall Width (in)	2.99 in
Locking Collar Outside Diameter (in)	3.25 in
Bolt Spacing Max (in)	7.88 in
Base Length (in)	9.61 in
Centerline to Outermost Bearing Face (in)	2.06 in
Length Through Bore (in)	2.99 in
Housing Cast Face to Outermost Bearing Face (in)	0.99 in
Bolt Spacing Min (in)	7.64 in

Technical Specifications

Fixed/Expansion	Fixed
Housing Style	Pillow Block
Radial Dynamic Load Capacity (lb)	26,200 lb
End Cap	SEE AUX CAP KIT
Product	EP2B
Shaft Locking Type	Single Set Collar
Housing Material	Cast Iron
Misalignment Type	Dynamic
Housing Color	Black
Housing Type	Pillow Block, Two Bolt, Type E
Series	Solid-housed Pillow Blocks
Housing Construction	Solid
Cage Material	Steel
Static Load Rating (lb)	30,590 lb
Rolling Element	Spherical Roller
Seal Type	Multi-Lip Contact Seal
Available Seal Type	C Clearance Seal; T Triple Lip Seal
Ability to Relubricate	Yes
Setscrew Torque (in-lbs)	460 in/lbs
Maximum Speed (RPM)	2720 rpm
Primary Seal	BUNA TRIPLE LIP SEAL
Vibration Frequency Outer Ring Defect	0.1353 cps
Vibration Frequency Roller Spin	0.0554 cps
Vibration Frequency Fundamental Train	0.0071 cps
Misalignment Capability	±2.0° Misalignment - Dynamic
Lubricant	EXXON RONEX MP STD
Grease Fitting Thread Size	1/8 NPT
Vibration Frequency Inner Ring Defect	0.1814 cps
Housing Coating	POWDER COATED
Size Code	7
Lube Fitting Type	STRAIGHT AND 90 DEG FITTING
Max Operating Temperature (F)	225 °F
Max Operating Temperature (C)	107 °C

General Specifications

UPC	782934931079
Weight	10.29 LB
Packaged Length	9.56 IN
Packaged Width	4.00 IN
Packaged Height	5.50 IN
HTC	8483208080
Country of Origin	China
