Technical Specifications

Chain Category	Elevator
Overall Width/Pin Length (in)	4.37 in
Chain Sub-Category	Hi Load Elevator
Width Between Outer Plates (in)	2.94 in
Rated Working Load (lb/ft)	6,300 lb/ft
Base Catalog No	ER102B
Plate Depth (in)	1.5 in
Product	Hi Load Elevator
Plate Thickness (in)	0.38 in
Attachment Number	K2
Sprocket Unit	102B
Minimum Tensile Strength (lbs)	36,000 lb
Chain Pitch (in)	4 in
Series	Elevator Chain
Pin Diameter (in)	0.63 in
Attachment Spacing	4

General Specifications

UPC	793699623567
Weight	9.40 LB
Packaged Length	95.97 IN
Packaged Width	95.97 IN
Packaged Height	53.98 IN
HTC	7315120080
Country of Origin	Mexico
