• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The NFS Sprag one way clutch is designed with the same overall dimensions as medium series metric ball bearing.
• Manufactured with an inner race containing a key seat and out race containing key slots

Technical Specifications

Rated Torque Capacity (ft.-lbs.)	4.9
Type	CAM Clutches
Drag Torque (N-m)	.005
Model	NSS 8
Lubrication Type	The clutches are supplied with a protective coating of oil and must be lubricated before putting into service.
Keyway (in)	0.08 x 0.04 in
Keyway (mm)	2 x 1.0 mm
Maximum Overrunning Speed - Inner Race (rpm)	6,000
Rated Torque Capacity (N-m)	6.7
Drag Torque (lb-in)	.0444
Maximum Overrunning Speed - Outer Race (rpm)	3,000
Add'l Bearing Support Requirement	Yes
Backstopping Clutch	No
Indexing Clutch	Yes
Bore Size (in)	0.31496 in
Overrunning Clutch	Yes
Bore Size (mm)	8 mm
Product Type	NSS Series
Overall Diameter (in)	0.9 in
RPM Max. -inner Race	6,000
Outer Width (in)	0.3 in
Nominal Overrunning Drag (ft-lb)	0.004
Inner Race Width (in)	0.3 in

General Specifications

UPC	662460387758
Weight	0.08 LB
Packaged Length	2.60 IN
Packaged Width	2.50 IN
Packaged Height	1.20 IN
HTC	8483.60.4040
Country of Origin	Japan
