• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The NFS Sprag one way clutch is designed with the same overall dimensions as medium series metric ball bearing.
• Manufactured with an inner race containing a key seat and out race containing key slots

Technical Specifications

Model	NSS 35
Maximum Overrunning Speed - Inner Race (rpm)	1,600
Keyway (in)	0.39 x 0.10 in
Rated Torque Capacity (N-m)	136
Type	CAM Clutches
Drag Torque (N-m)	.03
Lubrication Type	The clutches are supplied with a protective coating of oil and must be lubricated before putting into service.
Maximum Overrunning Speed - Outer Race (rpm)	800
Rated Torque Capacity (ft.-lbs.)	100.3
Drag Torque (lb-in)	.2652
Keyway (mm)	10 x 2.4 mm
Add'l Bearing Support Requirement	Yes
Product Type	NSS Series
Indexing Clutch	Yes
Bore Size (mm)	35 mm
Backstopping Clutch	No
Overrunning Clutch	Yes
Bore Size (in)	1.377949 in

General Specifications

UPC	662460387703
Weight	0.69 LB
Packaged Length	3.50 IN
Packaged Width	3.50 IN
Packaged Height	0.90 IN
HTC	8483.60.4040
Country of Origin	Japan
