• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The NFS Sprag one way clutch is designed with the same overall dimensions as medium series metric ball bearing.
• Manufactured with an inner race containing a key seat and out race containing key slots

Technical Specifications

Maximum Overrunning Speed - Outer Race (rpm)	900
Rated Torque Capacity (N-m)	105
Keyway (in)	0.32 x 0.08 in
Keyway (mm)	8 x 2.0 mm
Type	CAM Clutches
Model	NSS 30
Drag Torque (lb-in)	.2652
Lubrication Type	The clutches are supplied with a protective coating of oil and must be lubricated before putting into service.
Drag Torque (N-m)	.03
Maximum Overrunning Speed - Inner Race (rpm)	1,800
Rated Torque Capacity (ft.-lbs.)	77.4
Add'l Bearing Support Requirement	Yes
Bore Size (mm)	30 mm
Bore Size (in)	1.181099 in
Product Type	NSS Series
Overrunning Clutch	Yes
Backstopping Clutch	No
Indexing Clutch	Yes
RPM Max. -inner Race	1,800
Overall Diameter (in)	2.4 in
Outer Width (in)	0.6 in
Inner Race Width (in)	0.6 in
Nominal Overrunning Drag (ft-lb)	0.022

General Specifications

UPC	662460387697
Weight	0.50 LB
Packaged Length	2.60 IN
Packaged Width	2.50 IN
Packaged Height	1.10 IN
HTC	8483.60.4040
Country of Origin	Japan
