• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The NFS Sprag one way clutch is designed with the same overall dimensions as medium series metric ball bearing.
• Manufactured with an inner race containing a key seat and out race containing key slots

Technical Specifications

Keyway (in)	0.39 x 0.10 in
Lubrication Type	The clutches are supplied with a protective coating of oil and must be lubricated before putting into service.
Rated Torque Capacity (N-m)	475
Drag Torque (N-m)	.42
Maximum Overrunning Speed - Inner Race (rpm)	1,400
Drag Torque (lb-in)	3.72
Maximum Overrunning Speed - Outer Race (rpm)	700
Type	CAM Clutches
Model	NFS 35
Keyway (mm)	10 x 2.4 mm
Rated Torque Capacity (ft.-lbs.)	350
Add'l Bearing Support Requirement	Yes
Overrunning Clutch	Yes
Backstopping Clutch	No
Product Type	NFS Series
Bore Size (mm)	35 mm
Indexing Clutch	Yes
Bore Size (in)	1.377949 in

General Specifications

UPC	662460387581
Weight	1.74 LB
Packaged Length	3.70 IN
Packaged Width	3.70 IN
Packaged Height	1.60 IN
HTC	8483.60.4040
Country of Origin	Japan
