• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• MZEU series has a dual metric ball bearing supported design with metric bores. It is suitable for overrunnng and middle speed backstopping.
• This one way sprag clutch has tapped holes to mount accessories

Technical Specifications

Rated Torque Capacity (N-m)	1015
Drag Torque (lb-ft)	0.361405
Keyway	10 X 3.3
Rated Torque Capacity (ft.-lbs.)	748.6244
Type	CAM Clutches
Bore Size Tolerances (mm)	+0.025/-0.000 mm
Bore Size Tolerances (in)	+0.0010/-0.0000 in
Drag Torque (N-m)	0.49
Model	MZEU 35
Add'l Bearing Support Requirement	No
Maximum Overrunning Speed - Outer Race (rpm)	300
Bore Size (mm)	35 mm
Bore Size (in)	1.377949 in
Maximum Overrunning Speed - Inner Race (rpm)	1,400
Backstopping Clutch	Yes
Overrunning Clutch	Yes
Indexing Clutch	No
Product Type	MZEU Series

General Specifications

UPC	662288930112
Weight	7.07 LB
Packaged Length	5.10 IN
Packaged Width	5.00 IN
Packaged Height	4.50 IN
HTC	8483.60.4040
Country of Origin	Japan
