• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The M series ball bearing clutch contain precision formed cams made from high quality steel and precision ground. Our most versatile clutch, this unit is the workhorse of the industry
• MO is made with felt grease seals to minimize drag for high speed inner race overrunning application. Delivered with standard grease lubrication

Technical Specifications

RPM Max. - Inner Race	2000
Mode of Operation	High Speed inner race overrunning
Overall Diameter (in)	7.125 in
Inner Race Width (in)	5 in
Type	CAM Clutches
RPM Max. - Outer Race	400
Product Type	M Series
Rated Torque Capacity (ft.-lbs.)	5,000
Clutch size code	700
Model	MO
Outer Width (in)	4.875 in
Add'l Bearing Support Requirement	No
Indexing Clutch	Yes
Bore (Max) (in)	2.9375 in
Bore Size (in)	2.75 in
Backstopping Clutch	Yes
Bore (Min) (in)	2 in
Overrunning Clutch	Yes
Lubrication Type	Grease
Nominal Overrunning Drag (ft-lb)	1.3

General Specifications

UPC	662288501916
Weight	43.00 LB
Packaged Length	7.25 IN
Packaged Width	7.25 IN
Packaged Height	5.50 IN
HTC	8483.60.4040
Country of Origin	Mexico
