• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The M series ball bearing clutch contain precision formed cams made from high quality steel and precision ground. Our most versatile clutch, this unit is the workhorse of the industry
• MO is made with felt grease seals to minimize drag for high speed inner race overrunning application. Delivered with standard grease lubrication

Technical Specifications

Outer Width (in)	3.625 in
Model	MO
Clutch size code	600
RPM Max. - Outer Race	700
Rated Torque Capacity (ft.-lbs.)	2,250
RPM Max. - Inner Race	2400
Inner Race Width (in)	3.75 in
Mode of Operation	High Speed inner race overrunning
Product Type	M Series
Type	CAM Clutches
Overall Diameter (in)	5.375 in
Add'l Bearing Support Requirement	No
Indexing Clutch	Yes
Bore (Max) (in)	2 in
Bore Size (in)	1.5 in
Bore (Min) (in)	1.25 in
Backstopping Clutch	Yes
Overrunning Clutch	Yes
Lubrication Type	Grease
Nominal Overrunning Drag (ft-lb)	0.63

General Specifications

UPC	662288502241
Weight	20.00 LB
Packaged Length	6.20 IN
Packaged Width	6.70 IN
Packaged Height	4.10 IN
HTC	8483.60.4040
Country of Origin	Mexico
