• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The M series ball bearing clutch contain precision formed cams made from high quality steel and precision ground. Our most versatile clutch, this unit is the workhorse of the industry
• MI is recommended for high performance indexing applications requiring high indexing accuracy. Incorporates and low inertia cage and heavy duty inergizing spring for quick cam reaction

Technical Specifications

Outer Width (in)	3.625 in
Model	MI
Overall Diameter (in)	5.375 in
Type	CAM Clutches
Rated Torque Capacity (ft.-lbs.)	2,250
Inner Race Width (in)	3.75 in
Clutch size code	600
Mode of Operation	High Performance Indexing
Product Type	M Series
Add'l Bearing Support Requirement	No
Overrunning Clutch	Yes
Lubrication Type	Oil
Bore (Max) (in)	2 in
Backstopping Clutch	Yes
Indexing Clutch	Yes
Bore (Min) (in)	1.25 in
Bore Size (in)	1.75 in
Nominal Overrunning Drag (ft-lb)	0.63

General Specifications

UPC	662288501602
Weight	17.53 LB
Packaged Length	6.80 IN
Packaged Width	6.20 IN
Packaged Height	4.10 IN
HTC	8483.60.4040
Country of Origin	Mexico
