• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The M series ball bearing clutch contain precision formed cams made from high quality steel and precision ground. Our most versatile clutch, this unit is the workhorse of the industry
• MG is primarily used for general duty overriding, indexing, back-stopping. Offers precise spring energizing to provide ling overcunning life.

Technical Specifications

Inner Race Width (in)	3.75 in
RPM Max. - Inner Race	1800
Rated Torque Capacity (ft.-lbs.)	2,250
RPM Max. - Outer Race	700
Product Type	M Series
Overall Diameter (in)	5.375 in
Outer Width (in)	3.625 in
Mode of Operation	General duty all types
Clutch size code	600
Type	CAM Clutches
Model	MG
Add'l Bearing Support Requirement	No
Bore Size (in)	1.75 in
Indexing Clutch	Yes
Overrunning Clutch	Yes
Bore (Min) (in)	1.25 in
Bore (Max) (in)	2 in
Backstopping Clutch	Yes
Lubrication Type	Oil
Nominal Overrunning Drag (ft-lb)	0.63
RPM Max. -inner Race	1,800

General Specifications

UPC	662288501466
Weight	17.52 LB
Packaged Length	6.80 IN
Packaged Width	6.30 IN
Packaged Height	4.00 IN
HTC	8483.60.4040
Country of Origin	Mexico
