• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• The M series ball bearing clutch contain precision formed cams made from high quality steel and precision ground. Our most versatile clutch, this unit is the workhorse of the industry
• MG is primarily used for general duty overriding, indexing, back-stopping. Offers precise spring energizing to provide ling overcunning life.

Technical Specifications

Overall Diameter (in)	4.25 in
Mode of Operation	General duty all types
RPM Max. - Outer Race	750
Clutch size code	500
Outer Width (in)	3.375 in
Inner Race Width (in)	3.5 in
Rated Torque Capacity (ft.-lbs.)	1,175
RPM Max. - Inner Race	2400
Product Type	M Series
Type	CAM Clutches
Model	MG
Add'l Bearing Support Requirement	No
Lubrication Type	Oil
Bore (Min) (in)	0.875 in
Bore (Max) (in)	1.25 in
Backstopping Clutch	Yes
Indexing Clutch	Yes
Overrunning Clutch	Yes
Bore Size (in)	1.25 in
Nominal Overrunning Drag (ft-lb)	0.38

General Specifications

UPC	662288501251
Weight	11.00 LB
Packaged Length	4.25 IN
Packaged Width	4.25 IN
Packaged Height	3.63 IN
HTC	8483.60.4040
Country of Origin	Mexico
