• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

Type	CAM Clutches
Static Radial Load Rating (lb)	2630.3
RPM Max. - Outer Race	900
Dynamic Radial Load Rating (lb)	3529.7
RPM Max. -inner Race	1,800
Overall Diameter (in)	3.15 in
Corner Radius	1.1
Overall Diameter (mm)	80 mm
Mounting Housing Diameter	3.149/3.1483
Mounting Shaft Diameter	1.5743/1.5733
Overall Width (in)	1.063 in
Add'l Bearing Support Requirement	No
Indexing Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	191.8
Product Type	KK Series
Bore Size (mm)	40 mm
Overrunning Clutch	Yes
Backstopping Clutch	Yes

General Specifications

UPC	662288927624
Weight	1.90 LB
Packaged Length	3.80 IN
Packaged Width	3.80 IN
Packaged Height	1.50 IN
HTC	8483.60.4040
Country of Origin	Japan
