• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

Mounting Housing Diameter	2.834/2.8333
Lubrication Type	Grease
Dynamic Radial Load Rating (lb)	3034.9
Overall Diameter (mm)	72 mm
Corner Radius	1.1
Type	CAM Clutches
Static Radial Load Rating (lb)	2180.6
RPM Max. -inner Race	1,800
RPM Max. - Outer Race	1000
Overall Width (in)	0.669 in
Overall Diameter (in)	2.835 in
Mounting Shaft Diameter	1.3793/1.3787
Add'l Bearing Support Requirement	No
Backstopping Clutch	Yes
Bore Size (mm)	35 mm
Overrunning Clutch	Yes
Indexing Clutch	Yes
Product Type	KK Series
Rated Torque Capacity (ft.-lbs.)	127.6

General Specifications

UPC	662288927549
Weight	0.70 LB
HTC	8483.60.4040
Country of Origin	Japan
