• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

RPM Max. -inner Race	2,000
Mounting Shaft Diameter	1.1822/1.1817
Corner Radius	1
Mounting Housing Diameter	2.4403/2.4396
Overall Width (in)	0.63 in
Overall Diameter (in)	2.441 in
Dynamic Radial Load Rating (lb)	2675.2
Lubrication Type	Grease
Type	CAM Clutches
RPM Max. - Outer Race	1100
Overall Diameter (mm)	62 mm
Static Radial Load Rating (lb)	1776
Add'l Bearing Support Requirement	No
Backstopping Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	103.3
Indexing Clutch	Yes
Product Type	KK Series
Bore Size (mm)	30 mm
Overrunning Clutch	Yes
Nominal Overrunning Drag (ft-lb)	0.0221
Inner Race Width (in)	0.63 in
Outer Width (in)	0.63 in
Bore Size (in)	1.181 in

General Specifications

UPC	662288927495
Weight	0.54 LB
Packaged Length	3.20 IN
Packaged Width	3.20 IN
Packaged Height	1.00 IN
HTC	8483.60.4040
Country of Origin	Japan
