• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

Mounting Housing Diameter	2.4403/2.4396
Static Radial Load Rating (lb)	1776
Corner Radius	1
Type	CAM Clutches
Overall Diameter (in)	2.441 in
Overall Diameter (mm)	62 mm
RPM Max. - Outer Race	1100
Overall Width (in)	0.827 in
Mounting Shaft Diameter	1.1822/1.1817
Dynamic Radial Load Rating (lb)	2675.2
RPM Max. -inner Race	2,000
Add'l Bearing Support Requirement	No
Backstopping Clutch	Yes
Bore Size (mm)	30 mm
Rated Torque Capacity (ft.-lbs.)	103.3
Indexing Clutch	Yes
Overrunning Clutch	Yes
Product Type	KK Series

General Specifications

UPC	662288927525
Weight	0.68 LB
Packaged Length	3.20 IN
Packaged Width	3.10 IN
Packaged Height	1.10 IN
HTC	8483.60.4040
Country of Origin	Japan
