• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

Lubrication Type	The clutches are supplied with a protective coating of oil and must be lubricated before putting into service.
Mounting Housing Diameter	1.5743/1.5737
Static Radial Load Rating (lb)	831.8
RPM Max. -inner Race	3,500
Overall Diameter (mm)	40 mm
Mounting Shaft Diameter	0.6702/0.6698
Dynamic Radial Load Rating (lb)	1573.7
Overall Width (in)	0.472 in
RPM Max. - Outer Race	1900
Type	CAM Clutches
Corner Radius	0.6
Overall Diameter (in)	1.575 in
Add'l Bearing Support Requirement	No
Bore Size (mm)	17 mm
Indexing Clutch	Yes
Overrunning Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	31.7
Backstopping Clutch	Yes
Product Type	KK Series

General Specifications

UPC	662288927358
Weight	0.20 LB
Packaged Length	2.60 IN
Packaged Width	2.50 IN
Packaged Height	1.10 IN
HTC	8483.60.4040
Country of Origin	Japan
