• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

RPM Max. - Outer Race	1900
RPM Max. -inner Race	3,500
Overall Diameter (in)	1.575 in
Overall Diameter (mm)	40 mm
Overall Width (in)	0.669 in
Lubrication Type	Grease
Mounting Housing Diameter	1.5743/1.5737
Type	CAM Clutches
Static Radial Load Rating (lb)	831.8
Dynamic Radial Load Rating (lb)	1573.7
Corner Radius	0.6
Mounting Shaft Diameter	0.669/0.6682
Add'l Bearing Support Requirement	No
Indexing Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	31.7
Product Type	KK Series
Backstopping Clutch	Yes
Overrunning Clutch	Yes
Bore Size (mm)	17 mm

General Specifications

UPC	662288927389
Weight	0.22 LB
HTC	8483.60.4040
Country of Origin	Japan
