• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• This general bearing clutch can be utilized with both oil and grease lubrication. Self contained ball bearing and cam clutch
• KK Clutch is available in several configurations with different sealing options and inner and outer keyway options.

Technical Specifications

Static Radial Load Rating (lb)	726.1
Corner Radius	0.6
RPM Max. -inner Race	3,600
Overall Diameter (in)	1.378 in
Overall Diameter (mm)	35 mm
Mounting Shaft Diameter	0.5915/0.5911
Overall Width (in)	0.433 in
Dynamic Radial Load Rating (lb)	1337.6
Type	CAM Clutches
Mounting Housing Diameter	1.3774/1.3768
RPM Max. - Outer Race	2000
Add'l Bearing Support Requirement	No
Product Type	KK Series
Rated Torque Capacity (ft.-lbs.)	21.4
Bore Size (mm)	15 mm
Backstopping Clutch	Yes
Indexing Clutch	Yes
Overrunning Clutch	Yes

General Specifications

UPC	662288927303
Weight	0.15 LB
Packaged Length	2.70 IN
Packaged Width	2.50 IN
Packaged Height	1.20 IN
HTC	8483.60.4040
Country of Origin	Japan
