• Morse Mechanical Clutches offer the most complete and versatile selection of backstop, overriding, and index Clutches in the industry
• HT series clutch is designed for indexing operations. Not symmetrical so order according to the rotation required
• Created for applications requiring space restrictions

Technical Specifications

Snap Ring Ball Brg (Unfurnished)	304/205
Useable depth of thread	.375
Lubrication Type	Automatic Transmission Fluid - Must Be Added Before Use
Overall Diameter (in)	3.5625 in
Model	HT20
Number of Tapped Mounting Holes	4
Mounting Bolt Circle Diameter	2.75
Tapped Hole Thread Size	5/16-24
Nominal Overrunning Drag (ft-lb)	3.4
Bearing Counterbore Diameter	2.0470/2.0475
Configuration	LH
Rated Torque Capacity (ft.-lbs.)	154
Type	CAM Clutches
Overall Width (in)	2.28125 in
Add'l Bearing Support Requirement	No
Backstopping Clutch	Yes
Indexing Clutch	Yes
Bore Size (in)	1.3125 in
Length Through Bore (in)	1.6875 in
Product Type	HT Series
Overrunning Clutch	Yes
Bore (Min) (in)	.4875/.4900 in

General Specifications

UPC	662288384977
Weight	4.87 LB
Packaged Length	4.70 IN
Packaged Width	4.40 IN
Packaged Height	3.30 IN
HTC	8483.60.4040
Country of Origin	Mexico
