• Unmatched Quality and Performance in Morse Brand Chain in conveying chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	0.625 in
Number of Connecting Links Included	1
Roller Width (in)	0.3125 in
Pin Diameter (in)	0.156 in
Number of Strands/Width	1
Material	Steel
Chain Construction	Riveted
Link Type	Roller Link
Chain Type	Large Roller Conveyor
Product Type	Roller Chain
Chain Pitch (in)	1 in
Chain Family	C2042
Side Plate Configuration	Straight
Total Length (ft)	10 ft
Pin Length (in)	0.63 in
Plate Thickness (in)	0.06 in
Base Catalog No	C2042
Inside Plate Height (in)	0.466 in

General Specifications

UPC	662288455646
Weight	0.57 LB
Packaged Length	9.30 IN
Packaged Width	9.30 IN
Packaged Height	1.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
