• Clutches Require Bearing support to assure concentricity between inner and outer races. Taper on this shaft should not exceed .0002 inches per inch.

Technical Specifications

Type	Mechanical Clutches
Bearing Size to Use with Clutch	207
Model	B207A
Overall Width (in)	1.125 in
Std Package Quantity	1
Overall Diameter (in)	2.8326 in
Key Size	1/4 x 1/8 in
RPM Max. - Inner Race (shaft)	2,000
Add'l Bearing Support Requirement	Yes
Product Type	B200 Series
Backstopping Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	275
Overrunning Clutch	Yes
Bore Size (in)	1.657 in
Indexing Clutch	Yes
RPM Max. -inner Race	2,000
Outer Width (in)	1.125 in
Lubrication Type	Grease

General Specifications

UPC	662961739094
Weight	1.25 LB
Packaged Length	3.70 IN
Packaged Width	3.30 IN
Packaged Height	2.40 IN
HTC	8483.60.4040
Country of Origin	Mexico
