• Clutches Require Bearing support to assure concentricity between inner and outer races. Taper on this shaft should not exceed .0002 inches per inch.

Technical Specifications

Bearing Size to Use with Clutch	206
Overall Width (in)	1.125 in
Key Size	1/4 x 1/8 in
RPM Max. - Inner Race (shaft)	2,000
Overall Diameter (in)	2.4388 in
Model	B206A
Type	Mechanical Clutches
Std Package Quantity	1
Add'l Bearing Support Requirement	Yes
Backstopping Clutch	Yes
Product Type	B200 Series
Overrunning Clutch	Yes
Rated Torque Capacity (ft.-lbs.)	175
Bore Size (in)	1.29 in
Indexing Clutch	Yes

General Specifications

UPC	662288407959
Weight	1.01 LB
Packaged Length	3.70 IN
Packaged Width	3.30 IN
Packaged Height	2.30 IN
HTC	8483.60.4040
Country of Origin	Mexico
