• Clutches Require Bearing support to assure concentricity between inner and outer races. Taper on this shaft should not exceed .0002 inches per inch.

Technical Specifications

RPM Max. - Inner Race (shaft)	2,500
Std Package Quantity	1
Model	B205A
Bearing Size to Use with Clutch	205
Overall Width (in)	1 in
Overall Diameter (in)	2.0448 in
Type	Mechanical Clutches
Key Size	3/16 x 3/32 in
Add'l Bearing Support Requirement	Yes
Indexing Clutch	Yes
Product Type	B200 Series
Rated Torque Capacity (ft.-lbs.)	80
Backstopping Clutch	Yes
Bore Size (in)	0.93 in
Overrunning Clutch	Yes

General Specifications

UPC	662288407942
Weight	0.74 LB
Packaged Length	3.80 IN
Packaged Width	3.20 IN
Packaged Height	2.40 IN
HTC	8483.60.4040
Country of Origin	Mexico
