• Clutches Require Bearing support to assure concentricity between inner and outer races. Taper on this shaft should not exceed .0002 inches per inch.

Technical Specifications

Bearing Size to Use with Clutch	204
Std Package Quantity	1
Type	Mechanical Clutches
Model	B204A
Key Size	3/16 x 3/32 in
Overall Diameter (in)	1.8483 in
Overall Width (in)	1 in
RPM Max. - Inner Race (shaft)	2,500
Add'l Bearing Support Requirement	Yes
Backstopping Clutch	Yes
Bore Size (in)	0.74 in
Rated Torque Capacity (ft.-lbs.)	50
Product Type	B200 Series
Overrunning Clutch	Yes
Indexing Clutch	Yes
Outer Width (in)	1 in
Lubrication Type	Grease
RPM Max. -inner Race	2,500

General Specifications

UPC	662288407935
Weight	1.04 LB
Packaged Length	3.30 IN
Packaged Width	3.70 IN
Packaged Height	2.30 IN
HTC	8483.60.4040
Country of Origin	Mexico
