• Clutches Require Bearing support to assure concentricity between inner and outer races. Taper on this shaft should not exceed .0002 inches per inch.

Technical Specifications

Model	B203A
Bearing Size to Use with Clutch	203
Type	Mechanical Clutches
Overall Width (in)	1 in
RPM Max. - Inner Race (shaft)	2,500
Key Size	1/8 x 1/16 in
Std Package Quantity	1
Overall Diameter (in)	1.5728 in
Add'l Bearing Support Requirement	Yes
Rated Torque Capacity (ft.-lbs.)	39
Bore Size (in)	0.65 in
Overrunning Clutch	Yes
Indexing Clutch	Yes
Product Type	B200 Series
Backstopping Clutch	Yes

General Specifications

UPC	662288407928
Weight	0.50 LB
Packaged Length	2.75 IN
Packaged Width	2.00 IN
Packaged Height	2.75 IN
HTC	8483.60.4040
Country of Origin	Mexico
