• Up to 10 degrees misalignment
• Resilient Design
• Absorbs Vibration
• Exposed and shrouded bolt configurations

Technical Specifications

Max. Bore w/SS over KW (in)	2.375 in
Bore Type	Plain Bore
Coupling Size	902
Flange Type	Round
Max Bore w/SS at 180° to KW (in)	2.75 in
Stock Bore (in)	1 in
Speed Max (rpm)	4,200 rpm
Coupling Type	Elastomeric Coupling
Measurement System	Imperial
Lube/Non-Lube	Non-Lubricated
Torque Rating (in-lb)	6,300 in/lbs
Torque Rating (ft-lb)	525 ft/lbs
Bore Size Min (in)	1 in

General Specifications

UPC	662288372028
Weight	19.04 LB
Packaged Length	8.30 IN
Packaged Width	8.40 IN
Packaged Height	4.90 IN
HTC	8483.90.8010
Country of Origin	Taiwan, Republic of China
