• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.625 in
Number of Connecting Links Included	1
Number of Strands/Width	1
Roller Diameter (in)	0.625 in
Chain Construction	Riveted
Chain Family	80
Material	Steel
Pin Diameter (in)	0.312 in
Chain Type	Standard
Chain Pitch (in)	1 in
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Pin Length (in)	1.274 in
Minimum Tensile Strength (lbs)	12,500 lb
Width Over Pins/Total Width (in)	1.274 in
Plate Thickness (in)	0.125 in
Total Length (ft)	10 ft
Inside Plate Height (in)	0.934 in
Side Plate Configuration	Hourglass
Base Catalog No	80

General Specifications

UPC	662288395232
Weight	1.85 LB
Packaged Length	11.70 IN
Packaged Width	11.30 IN
Packaged Height	1.60 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
