• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Width (in)	0.625 in
Number of Connecting Links Included	10
Pin Diameter (in)	0.312 in
Roller Diameter (in)	0.625 in
Number of Strands/Width	1
Chain Construction	Riveted
Chain Family	80
Material	Steel
Chain Type	Standard
Chain Pitch (in)	1 in
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	0.934 in
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	12,500 lb
Base Catalog No	80
Total Length (ft)	100 ft
Pin Length (in)	1.274 in
Plate Thickness (in)	0.125 in
Width Over Pins/Total Width (in)	1.274 in

General Specifications

UPC	662288461838
Weight	1.80 LB
Packaged Length	14.00 IN
Packaged Width	14.00 IN
Packaged Height	15.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
