• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.312 in
Number of Strands/Width	3
Material	Steel
Chain Construction	Riveted
Roller Width (in)	0.625 in
Roller Diameter (in)	0.625 in
Chain Family	80
Number of Connecting Links Included	1
Product Type	Roller Chain
Chain Type	Heavy
Chain Pitch (in)	1 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Total Length (ft)	10 ft
Base Catalog No	80H-3
Inside Plate Height (in)	0.934 in
Side Plate Configuration	Hourglass
Transverse Pitch (in)	1.389 in
Pin Length (in)	3.971 in
Plate Thickness (in)	0.156 in
Width Over Pins/Total Width (in)	3.971 in

General Specifications

UPC	662288860266
Weight	6.16 LB
Packaged Length	11.70 IN
Packaged Width	11.70 IN
Packaged Height	4.30 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
