• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.312 in
Roller Diameter (in)	0.625 in
Chain Construction	Cottered
Material	Steel
Number of Connecting Links Included	1
Roller Width (in)	0.625 in
Number of Strands/Width	1
Chain Family	80
Product Type	Roller Chain
Chain Pitch (in)	1 in
Chain Type	Standard
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Pin Length (in)	1.274 in
Inside Plate Height (in)	0.934 in
Base Catalog No	80C
Total Length (ft)	10 ft
Plate Thickness (in)	0.125 in
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	1.274 in

General Specifications

UPC	662288395218
Weight	1.90 LB
Packaged Length	11.70 IN
Packaged Width	11.30 IN
Packaged Height	1.70 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
