• Up to 10 degrees misalignment
• Resilient Design
• Absorbs Vibration
• Exposed and shrouded bolt configurations

Technical Specifications

Max. Bore w/SS over KW (in)	2.25 in
Coupling Size	802
Bore Type	Plain Bore
Max Bore w/SS at 180° to KW (in)	2.5 in
Flange Type	Round
Stock Bore (in)	1 in
Speed Max (rpm)	4,400 rpm
Lube/Non-Lube	Non-Lubricated
Torque Rating (in-lb)	4,668 in/lbs
Coupling Type	Elastomeric Coupling
Measurement System	Imperial
Torque Rating (ft-lb)	389 ft/lbs
Bore Size Min (in)	1 in

General Specifications

UPC	662288372011
Weight	11.94 LB
Packaged Length	7.20 IN
Packaged Width	7.40 IN
Packaged Height	5.40 IN
HTC	8483.90.8010
Country of Origin	Taiwan, Republic of China
