• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Family	80
Number of Connecting Links Included	1
Roller Diameter (in)	0.625 in
Chain Construction	Cottered
Roller Width (in)	0.625 in
Number of Strands/Width	3
Material	Steel
Pin Diameter (in)	0.312 in
Chain Pitch (in)	1 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Plate Thickness (in)	0.125 in
Total Length (ft)	10 ft
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	3.585 in
Pin Length (in)	3.585 in
Base Catalog No	80-3
Minimum Tensile Strength (lbs)	37,500 lb
Inside Plate Height (in)	0.934 in
Transverse Pitch (in)	1.153 in

General Specifications

UPC	662288455400
Weight	5.34 LB
Packaged Length	11.90 IN
Packaged Width	11.60 IN
Packaged Height	4.10 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
