• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	0.625 in
Material	Steel
Number of Strands/Width	2
Chain Family	80
Pin Diameter (in)	0.312 in
Chain Construction	Cottered
Roller Width (in)	0.625 in
Number of Connecting Links Included	1
Chain Type	Standard
Product Type	Roller Chain
Chain Pitch (in)	1 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	0.934 in
Base Catalog No	80-2
Pin Length (in)	2.432 in
Minimum Tensile Strength (lbs)	25,000 lb
Plate Thickness (in)	0.125 in
Transverse Pitch (in)	1.153 in
Width Over Pins/Total Width (in)	2.432 in
Total Length (ft)	10 ft
Side Plate Configuration	Hourglass

General Specifications

UPC	662288395256
Weight	3.60 LB
Packaged Length	11.90 IN
Packaged Width	12.10 IN
Packaged Height	3.00 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
