• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Family	100
Number of Strands/Width	1
Chain Construction	Cottered
Roller Width (in)	0.75 in
Material	Steel
Number of Connecting Links Included	1
Pin Diameter (in)	0.375 in
Roller Diameter (in)	0.75 in
Chain Pitch (in)	1.25 in
Chain Type	High Strength
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	1.166 in
Plate Thickness (in)	0.187 in
Pin Length (in)	1.684 in
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	1.684 in
Base Catalog No	8-100H
Total Length (ft)	10 ft

General Specifications

UPC	662288455189
Weight	3.15 LB
Packaged Length	13.80 IN
Packaged Width	13.60 IN
Packaged Height	2.60 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
