• Up to 10 degrees misalignment
• Resilient Design
• Absorbs Vibration
• Exposed and shrouded bolt configurations

Technical Specifications

Flange Type	Round
Stock Bore (in)	0.875 in
Max. Bore w/SS over KW (in)	1.75 in
Coupling Size	702
Max Bore w/SS at 180° to KW (in)	2.125 in
Bore Type	Plain Bore
Torque Rating (in-lb)	3,408 in/lbs
Coupling Type	Elastomeric Coupling
Measurement System	Imperial
Speed Max (rpm)	4,600 rpm
Lube/Non-Lube	Non-Lubricated
Torque Rating (ft-lb)	284 ft/lbs
Bore Size Min (in)	0.875 in

General Specifications

UPC	662288372004
Weight	8.19 LB
Packaged Length	6.20 IN
Packaged Width	6.30 IN
Packaged Height	2.70 IN
HTC	8483.90.8010
Country of Origin	Taiwan, Republic of China
