• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	0.468 in
Pin Diameter (in)	0.234 in
Chain Construction	Riveted
Number of Connecting Links Included	1
Number of Strands/Width	1
Chain Family	60
Roller Width (in)	0.5 in
Material	Stainless Steel
Chain Type	Stainless Steel
Chain Pitch (in)	0.75 in
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Base Catalog No	60SS
Pin Length (in)	0.99 in
Plate Thickness (in)	0.094 in
Width Over Pins/Total Width (in)	0.99 in
Total Length (ft)	10 ft
Inside Plate Height (in)	0.7 in
Side Plate Configuration	Hourglass
Minimum Tensile Strength (lbs)	0.162 lb

General Specifications

UPC	662288791218
Weight	1.08 LB
Packaged Length	9.40 IN
Packaged Width	9.60 IN
Packaged Height	1.40 IN
HTC	7315.11.0060
Country of Origin	Japan
