• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Roller Diameter (in)	0.468 in
Number of Strands/Width	1
Chain Family	60
Material	Steel
Number of Connecting Links Included	5
Chain Construction	Riveted
Roller Width (in)	0.5 in
Pin Diameter (in)	0.234 in
Chain Pitch (in)	0.75 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	0.7 in
Base Catalog No	60
Total Length (ft)	50 ft
Minimum Tensile Strength (lbs)	7,030 lb
Width Over Pins/Total Width (in)	0.99 in
Plate Thickness (in)	0.094 in
Side Plate Configuration	Hourglass
Pin Length (in)	0.99 in

General Specifications

UPC	662288395171
Weight	1.09 LB
Packaged Length	13.80 IN
Packaged Width	13.90 IN
Packaged Height	14.10 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
