• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Family	60
Chain Construction	Riveted
Number of Strands/Width	1
Pin Diameter (in)	0.234 in
Material	Steel
Number of Connecting Links Included	1
Roller Diameter (in)	0.468 in
Roller Width (in)	0.5 in
Chain Type	Standard
Chain Pitch (in)	0.75 in
Product Type	Roller Chain
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Total Length (ft)	10 ft
Width Over Pins/Total Width (in)	0.99 in
Plate Thickness (in)	0.094 in
Base Catalog No	60
Inside Plate Height (in)	0.7 in
Side Plate Configuration	Hourglass
Pin Length (in)	0.99 in
Minimum Tensile Strength (lbs)	7,030 lb

General Specifications

UPC	662288395164
Weight	1.04 LB
Packaged Length	10.00 IN
Packaged Width	9.90 IN
Packaged Height	1.40 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
