• Unmatched Quality and Performance in Morse Brand Chain
• Roller chain with the self-lubricating properties of oil impregnated, sintered metal bushings to assure longer, more reliable chain service where external lubrication is prohibited or severely limited.
• Available in package quantities or via quick-turnaround cut-to-length
• Rigid manufacturing processes result in a fully-featured chain.

Technical Specifications

Roller Width (in)	0.5 in
Chain Family	60
Chain Construction	Riveted
Number of Connecting Links Included	1
Material	Steel
Number of Strands/Width	1
Pin Diameter (in)	0.234 in
Roller Diameter (in)	0.468 in
Chain Pitch (in)	0.75 in
Product Type	Roller Chain
Chain Type	Sintered Bushing
Coating	Uncoated
Measurement System	Imperial
Standard Met	ANSI B29.1
Width Over Pins/Total Width (in)	0.99 in
Inside Plate Height (in)	0.7 in
Total Length (ft)	10 ft
Base Catalog No	60LL
Pin Length (in)	0.99 in
Plate Thickness (in)	0.094 in
Side Plate Configuration	Hourglass

General Specifications

UPC	662288400509
Weight	0.97 LB
Packaged Length	10.20 IN
Packaged Width	10.00 IN
Packaged Height	1.60 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
