• Unmatched Quality and Performance in Morse Brand Chain
• Roller chain with the self-lubricating properties of oil impregnated, sintered metal bushings to assure longer, more reliable chain service where external lubrication is prohibited or severely limited.
• Available in package quantities or via quick-turnaround cut-to-length
• Rigid manufacturing processes result in a fully-featured chain.

Technical Specifications

Number of Connecting Links Included	1
Roller Diameter (in)	0.468 in
Material	Steel
Chain Construction	Cottered
Chain Family	60
Pin Diameter (in)	0.234 in
Number of Strands/Width	1
Roller Width (in)	0.5 in
Chain Pitch (in)	0.75 in
Product Type	Roller Chain
Chain Type	Sintered Bushing
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Width Over Pins/Total Width (in)	0.99 in
Inside Plate Height (in)	0.7 in
Plate Thickness (in)	0.094 in
Side Plate Configuration	Hourglass
Total Length (ft)	10 ft
Base Catalog No	60LL
Pin Length (in)	0.99 in

General Specifications

UPC	662288400523
Weight	1.04 LB
Packaged Length	10.00 IN
Packaged Width	9.90 IN
Packaged Height	1.40 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
