• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Strands/Width	2
Roller Width (in)	0.5 in
Roller Diameter (in)	0.468 in
Number of Connecting Links Included	1
Chain Family	60
Pin Diameter (in)	0.234 in
Chain Construction	Riveted
Material	Steel
Chain Type	Standard
Chain Pitch (in)	0.75 in
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Inside Plate Height (in)	0.7 in
Width Over Pins/Total Width (in)	1.893 in
Plate Thickness (in)	0.094 in
Side Plate Configuration	Hourglass
Total Length (ft)	10 ft
Base Catalog No	60-2
Pin Length (in)	1.893 in
Transverse Pitch (in)	0.897 in
Minimum Tensile Strength (lbs)	14,060 lb

General Specifications

UPC	662288395201
Weight	1.97 LB
Packaged Length	10.80 IN
Packaged Width	10.70 IN
Packaged Height	2.30 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
