• Unmatched Quality and Performance in Morse Brand Chain
• 304 Series Stainless Steel for the most corrosive environments
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Pin Diameter (in)	0.2 in
Number of Strands/Width	1
Material	Stainless Steel
Roller Width (in)	0.375 in
Chain Construction	Riveted
Number of Connecting Links Included	1
Roller Diameter (in)	0.4 in
Chain Family	50
Chain Type	Stainless Steel
Product Type	Roller Chain
Chain Pitch (in)	0.625 in
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Minimum Tensile Strength (lbs)	0.108 lb
Plate Thickness (in)	0.08 in
Width Over Pins/Total Width (in)	0.79 in
Side Plate Configuration	Hourglass
Pin Length (in)	0.79 in
Base Catalog No	50SS
Inside Plate Height (in)	0.584 in
Total Length (ft)	10 ft

General Specifications

UPC	662288791201
Weight	0.76 LB
Packaged Length	8.80 IN
Packaged Width	8.40 IN
Packaged Height	1.30 IN
HTC	7315.11.0060
Country of Origin	Japan
