• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Chain Family	50
Roller Diameter (in)	0.4 in
Roller Width (in)	0.375 in
Number of Strands/Width	1
Number of Connecting Links Included	1
Material	Steel
Chain Construction	Riveted
Pin Diameter (in)	0.2 in
Chain Pitch (in)	0.625 in
Chain Type	Standard
Product Type	Roller Chain
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Base Catalog No	50
Pin Length (in)	0.79 in
Plate Thickness (in)	0.08 in
Inside Plate Height (in)	0.584 in
Total Length (ft)	10 ft
Minimum Tensile Strength (lbs)	4,882 lb
Side Plate Configuration	Hourglass
Width Over Pins/Total Width (in)	0.79 in

General Specifications

UPC	662288395096
Weight	0.76 LB
Packaged Length	9.20 IN
Packaged Width	9.30 IN
Packaged Height	1.50 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
