• Unmatched Quality and Performance in Morse Brand Chain
• Far exceeds ANSI performance standards. Rigid manufacturing processes result in a fully-featured chain.
• Available in package quantities or via quick-turnaround cut-to-length

Technical Specifications

Number of Connecting Links Included	10
Chain Construction	Riveted
Number of Strands/Width	1
Material	Steel
Pin Diameter (in)	0.2 in
Roller Width (in)	0.375 in
Roller Diameter (in)	0.4 in
Chain Family	50
Chain Pitch (in)	0.625 in
Product Type	Roller Chain
Chain Type	Standard
Coating	Uncoated
Standard Met	ANSI B29.1
Measurement System	Imperial
Minimum Tensile Strength (lbs)	4,882 lb
Plate Thickness (in)	0.08 in
Total Length (ft)	100 ft
Inside Plate Height (in)	0.584 in
Width Over Pins/Total Width (in)	0.79 in
Side Plate Configuration	Hourglass
Pin Length (in)	0.79 in
Base Catalog No	50

General Specifications

UPC	662288395119
Weight	0.72 LB
Packaged Length	11.20 IN
Packaged Width	11.00 IN
Packaged Height	11.10 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
