• Unmatched Quality and Performance in Morse Brand Chain
• All components are plated before assembly
• Available in package quantities or via quick-turnaround cut-to-length
• The strength of carbon steel with corrosion protection

Technical Specifications

Chain Family	50
Number of Strands/Width	1
Number of Connecting Links Included	1
Roller Diameter (in)	0.4 in
Chain Construction	Riveted
Material	Steel
Roller Width (in)	0.375 in
Coating	Moisture Guard
Pin Diameter (in)	0.2 in
Chain Type	Moisture Guard
Chain Pitch (in)	0.625 in
Product Type	Roller Chain
Standard Met	ANSI B29.1
Measurement System	Imperial
Base Catalog No	50MG
Width Over Pins/Total Width (in)	0.79 in
Plate Thickness (in)	0.08 in
Total Length (ft)	10 ft
Inside Plate Height (in)	0.584 in
Pin Length (in)	0.79 in
Side Plate Configuration	Hourglass

General Specifications

UPC	662288806011
Weight	0.76 LB
Packaged Length	9.20 IN
Packaged Width	9.20 IN
Packaged Height	1.10 IN
HTC	7315.11.0060
Country of Origin	Taiwan, Republic of China
